Drive Rack PA dbx Professional Audio Loudspeaker Control System (Used)

• More information and pictures available upon request.
• Sold As-Is. Ask questions before purchase.

Details

Brand:

• dbx

Model:

• DriveRack PA Complete Equalization and Loudspeaker Control System

Analog Inputs:

Number of Inputs: (2) Line inputs. (1) RTA Mic input

Connectors: (2) Female XLR line inputs. XLR RTA Mic input

Type: Electronically balanced, RF filtered

Impedance: > 40k Ω

Max input line level: +20dBu

CMRR: > 45dB

RTA Mic Phantom Voltage: +15VDC

RTA Mic EIN: < -110dBu, 22Hz-22kHz,150Ω

Analog Outputs:

Number of Outputs: 6

Connectors: Male XLR

Type: Electronically balanced/RF filtered

Impedance: 120 ohms

Max Output Level: +20dBu
